Designed for immersive formats like Dolby Atmos and all performance-critical high-channel-count Dante applications, RedNet PCIeNX delivers 128 x128 audio channels (up to 192kHz) with ultra-low latency.
•128x128 channels (24-bit/192kHz) with ultra-low round-trip latency
•Perfect for large recording sessions and post-production work using Dolby Atmos and other immersive formats
•Dual Ethernet RJ-45 connections allow for both switched and redundant mode, offering flexible connectivity
•Supports the latest standards, including AES67 and compliance for SMPTE ST 2110 (DDM required)
•Compatible with Windows or Mac computers (Intel and Apple Silicon supported)
•Easily installed in a PCIe slot or Thunderbolt chassis
•Integrated network interface – allowing a single-cable connection for audio and network control
•Purchase with confidence. RedNet PCIeNX is backed by Focusrite’s 3-year warranty
- AES67 compatible : Yes
- Accessories included : - Cable ethernet cat6A 2m
- Configuration / management software : [logiciel_configuration_dante_domain_manager]
- Dante conversion resolution : [AE_antilarsen_resoconvdante002]
- Dante sampling frequency : [frequence192kz]
- Integrated web application : Yes
- Mains LED : Yes
- Number of Dante input channels : 128
- Number of Dante output channels : 128
- Number of RJ45 Gigabit ports : 2
